In 2016, I used a Black to provide data/power interfaces to various systems on a . A specialized variant of the board was used for the flight payload (radiation-hardened, no tin, etc, because ), but here is one under test. The power distribution board was created with @kicad!

The solitary BBB undergoes 1PPS signal integrity checks on an oscilloscope. The workbench BBB ensures that all signals comply with the External Platform communication specifications.
